Bobbin >> PQ
Introduce of PQ bobbin
PQ bobbin conformation is horizontal with through-holes; bobbin is made of thermoset and thermoplastic. The coilformers are made in gfr Polyamide PA66 of type p6g (RTI long-range temperature +125ºC). Pin material is tin bronze, tinned for solder-pins and brass, tinned for solder-tags. Max. solder temperature +350ºC, 2 sec. The coilformers are suitable for automatic winding on computer controlled machines. Surface mount is not available. Large terminals allow larger diameter magnet wire. PQ bobbin is easy to use. Cost: low to moderate. High efficient bobbin core with high permeability and excellent impedance characteristics are for effective AC line noise prevention. We apply a computerized process to generate mold design, auto forming, and injection. All ferrite bobbins are made of UL-approved materials.
Application of PQ bobbin
Bobbin PQ Series are for Ferrite Core used in Switching Power Transformers, Switch Transformer, Inductor, Coil, Filter, etc.
 |
Name: |
YX-2601 |
| series: | PQ |
| Specification: | YX-2601.pdf |
| Issue time: | 2005-3-9 |
|
 |
Name: |
YX-2602 |
| series: | PQ |
| Specification: | YX-2602.pdf |
| Issue time: | 2005-3-9 |
|
 |
Name: |
YX-2603 |
| series: |
PQ |
| Specification: | YX-2603.pdf |
| Issue time: |
2005-3-9 |
|
 |
Name: |
YX-2603-1 |
| series: | PQ |
| Specification: |
YX-2603-1.pdf |
| Issue time: |
2005-3-9 |
|
 |
Name: |
YX-3201 |
| series: | PQ |
| Specification: |
|
| Issue time: |
2005-3-9 |
|
 |
Name: |
YX-3201-1 |
| series: |
PQ |
| Specification: |
|
| Issue time: |
2005-3-9 |
|
 |
Name: |
YX-3202-1 |
| series: |
PQ |
| Specification: |
|
| Issue time: |
2005-3-9 |
|
